Quạt tản nhiệt ARCTIC P12 PWM PST CO - BLACK (Đen)

Thương hiệu ARCTIC Tình trạng Hết hàng
330.000₫

Bảo hành: 12 tháng

Tốc độ: 200 - 1800 vòng / phút
Lưu lượng gió: 56,3 CFM / 95,7 m³ / h
Áp suất tĩnh: 2,20 mm H₂O
Mức ồn: 0,3 Sone
Loại điều khiển: PWM PST
Đầu nối: 4-Pin-Connector + 4-Pin-Socket
Vòng bi quạt: Vòng bi kép
Điện áp : 12 V DC
Điện áp khởi động: 3,9 V
Dòng điện / Điện áp: 0,08 A / 12 V
Chiều dài cáp: 400 mm

Số lượng:

P12_PWM_PST_CO_S01_EN

OPTIMISED FOR STATIC PRESSURE

During the development of the new P12 PWM PST CO, special emphasis was placed on a focused airstream and thus a high static pressure. The fan guarantees extremely efficient cooling, even with increased air resistance. Therefore, the P12 PWM PST CO is particularly suitable for use on heatsinks and radiators.

P12_PWM_PST_CO_S02_EN

STRONG COOLING PERFORMANCE

Numerous improvements, such as an updated engine technology and a newly developed fan design, have noticeably increased the performance of P-fans. In internal performance tests leveled to 28 dB (A), the new P-fans left many competitors behind. More information can be found in our FAQ.

P12_PWM_PST_CO_S03_EN

MORE EFFICIENT TECHNOLOGY

The motor is powered by a Neodym-Iron-Boron-Magnet ring of the newest generation, which allows the new P12 PWM PST CO to run much more efficiently than its predecessors. This saves energy and lowers the coil temperature without comprimising the performance.

P12_PWM_PST_CO_S04

FOR CONTINUOUS OPERATION

The premium quality Japanese dual ball bearing allows continuous operation 24/7 without the slightest compromise in performance. Dust and high temperature are affecting this bearing a lot less than generic sleeve or one ball bearings and thus make it the perfect choice when reliability is essential.

P12_PWM_PST_CO_S05_EN

MAXIMUM QUIETNESS, MINIMUM VIBRATION

Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable. Due to a sinus-magnetizing the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter. Consequently, there is no need for rubber spacers due to the steady and smooth torque of the new motor.

P12_PWM_PST_CO_S06_EN

EXTENDED LIFE SPAN

A 10 °C lower motor temperature roughly doubles the life span of a fan. The new ARCTIC motor has a four times longer service life through its low coil temperature. Consequently, we have extended the warranty to 10 years.

P12_PWM_PST_CO_S07

200 TO 1800 RPM REGULATED VIA PWM

With a wide range of regulation and the PWM Sharing Technology (PST), the P12 PWM PST CO fan speed can be controlled synchronously with all your other fans together. This keeps noise at a minimum while guaranteeing maximum cooling performance when needed.

P12_PWM_PST_CO_S08

TWO WAY INSTALLATION

Push warm air out of the case

Pull cool air into your case
